◆技術水平基本(ben)參數(shu) Main technical parameters (請向下觀看(kan)產(chan)生太大的量案(an)例分(fen)享照片(pian)圖片(pian)供可以參考)
|
機(ji)氣應用 Model |
STR-9070/9080 |
STR-1010 |
|
事(shi)業艙的尺寸(cun) Internal size(mm) |
900×800×650 |
1000×1000×790 |
|
整(zheng)體尺寸(cun)圖 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
|
電源適(shi)配器 Power |
220V 50Hz |
220V 50Hz |
|
機械光照(zhao)燈 Machine floodlight |
一壺60W防暴燈 |
220V 13W節省燈 |
|
滾(gun)筒機承載 Roller bearing |
10-30Kg |
10-30Kg |
|
拆分器交流電動機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
|
拆分器(qi)新風量(liang) Separator air volume |
8.5m3/min |
8.5m3/min |
|
縮(suo)減空氣的源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
機設備毛重 Weight |
320kg |
380 kg |
◆企業產(chan)品(pin)特殊性 Product features
1. 來設計有新意、美化貴州大方、格局(ju)科學課(ke)、操作使用不方便;
2. 會自然控住會自然噴(pen)砂,必備時(shi)控噴(pen)砂,點動(dong)位置等模(mo)塊;
3. 輥(gun)子外徑及噴槍使用量可依據的(de)客戶(hu)標準設置建設;
4. 就可(ke)自動,又可(ke)手動,噴(pen)砂品級好,一(yi)機多使(shi)用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆選用標準 Applicable scope
采主要用于非(fei)常多小工件的的一(yi)(yi)鍵或一(yi)(yi)鍵噴砂(sha),舉例(li)子(zi):電木質品、小螺絲、塑料板材制
品、鈕(niu)扣、衣服(fu)拉鏈、壓(ya)克(ke)力板(ban)、機械設備零(ling)零(ling)件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
