◆商品特性 Product features
1. 設汁高(gao)大上,外型形象(xiang)美觀,環保性(xing)效率好;
2. 能調式(shi)颶風分開器(qi),能將能夠用研磨(mo)材料與肺部(bu)結(jie)節影有害(hai)氣體分開,好的研磨(mo)材料接著(zhu)便用;
3. 主要的備件(jian)利用(yong)創新型(xing)進(jin)品零部件(jian),食用(yong)生命長(chang);
4. 制作軸類零件漆(qi)層(ceng)均(jun);
5. 多工位器具設計的概念;運營員可也運營噴砂。可根據玩家需要,可以擇人工手動開啟機組或自主 ;可按老客戶符合要求定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適宜空間 Applicable scope
護墻板(ban),pc設(she)備(bei)殼,音響低音炮面版(ban),三(san)文治(zhi)烤盤等剖(pou)面及方體產品的噴砂生產。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆具體技術設備主要參數 Main technical parameters
|
機子型號規(gui)格 Model |
STR-多工位輸送式噴砂機 |
|
整套(tao)裝置外形尺寸(cun) Complete machine size(mm) |
3000×1000×1700 |
|
工作(zuo)的(de)位置(zhi) Work space(mm) |
2000×1000×800 |
|
外運(yun)送規(gui)格尺寸 Conveying the size(mm) |
500×1000×1000(2件(jian)) |
|
凈化箱長寬比 Dedust box sizes(mm) |
600×600×1800 |
|
離(li)心分離(li)設備交流電動(dong)機(ji) Separator motor |
220V 50HZ 550W |
|
拆分器風速(su) Separator air volume |
8.5m3/min |
|
減少(shao)冷空氣(qi)源(yuan) Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W隔爆燈 |
|
電腦重(zhong)量體積 Machine weight |
550kg |
